MC369 4 Row

All Aluminum Champion Radiator
4-Row Core Polished Tanks | Cools up to 900 hp

Radiator Dimensions:
Total: 19.25" tall x 33.88" wide
Core: 16" tall x 28.25" core x 2.75" thick
Inlet: 1.5" driver side
Outlet: 1.75" passenger side
Tanks: 3.25" thick
Tubes: 0.63" thick

Saddle Mounted

13 lb. Radiator Cap included
Transmission Cooler Included (1/2-20 Straight Thread, Inverted Flare)
Aluminum Shroud is also Available (sold separately)

When using Electric Fans:
Two 12" or 14" Electric fans recommended for this core size (sold separately)
