EC1009 2 Row

All Aluminum Champion Radiator
2-Row Core | Cools up to 400hp

Radiator Dimensions:
Total: 22.75" tall x 19.75" wide ( at lower bracket)
Core: 17" tall x 17.25" wide x 1.75" thick
Inlet: 1.5" driver side
Outlet: 1.75" passenger side
Tanks: 3" thick
Tubes: 0.75" thick

Bracket Mounted

13lb. Radiator Cap included
Transmission Cooler Included (1/2-20 Straight Thread, Inverted Flare)

When using electric fans:
One 16" Electric Cooling Fan recommended for this core size (sold separately)
