Description
Champion All Aluminum Radiator
3-Row Core | Cools up to 700hp
Includes bung on upper right for overflow (not shown)
For ECV w/6" extended front nose
Radiator Dimensions:
Total: 37.38" tall x 28.38" wide (with brackets)
Core: 31" tall x 26.75" wide x 2.5" thick
Inlet: 1.75" driver side
Outlet: 2" passenger side
Tanks: 3.13" thick
Tubes: 0.75" thick
OEM Mounting
13 lb. Radiator Cap included
NO Transmission Cooler included
LIFETIME WARRANTY
