CC959 3 Row

Champion All Aluminum Radiator
3-Row Core | Cools up to 700hp
This is the 18" tall core we do not carry the 21"

Radiator Dimensions:
Total: 22.87" tall x 30.13" wide (with brackets) x 2.5" deep
Core: 18" tall x 25.5" wide x 2.25" thick
Inlet: 1.5" drivers side
Outlet: 1.75" passenger side
Tanks: 2.5"
Tubes: 0.63" thick

Bracket Mounted

13 lb. Radiator Cap included
Transmission Cooler included (1/8-27NPT)
