CC6167ECO 3 Row Lower Pass Outlet

Champion All Aluminum Radiator
3-Row Core | Cools up to 450hp
This is a direct replacement VS the other 2 choices

Radiator Dimensions:
Total: 25.13 tall" x 19.5" wide (with brackets)
Core: 20" tall x 17.13" wide x 2" thick
Inlet: 1.5" passenger side
Outlet: 1.75" passenger side
Tanks: 2.5" thick
Tubes: 0.63" thick

Bracket Mounted

13 lb. Radiator Cap included
Transmission Cooler Included (1/8-27npt)

When using electric fans:
One 16" Electric fan recommended for this core size
