CC58PO 3 Row

Champion Cooling All-Aluminum Radiator
3 Row Core | Cools up to 650hp

Radiator Dimensions:
Total: 25.88" x 26.25" (with brackets)
Core: 19.88" Tall x 22" wide x 2" thick
Inlet: 1.75" drivers side
Outlet: 2" passenger side
Tanks: 3.13" upper, 2.38" lower thick
Tubes: 0.63" thick

Bracket Mounted

13 lb. Radiator Cap included
Transmission Cooler included (1/4-18 NPT)

When using electric fans:
One 16" or (2) 11" SPAL Electric fan(s) recommended for this core size (sold separately)
