CC54OLCH 3 Row Chevy Motor

Champion Cooling All-Aluminum Radiator
3 Row Core | Cools up to 650hp
Chevy Conversions

Radiator Dimensions:
Total: 27.13" tall x 26.13" wide (with brackets)
Core: 21.25" tall x 23.5" wide x 2.25" thick
Inlet: 1.5" drivers side
Outlet: 1.75" passenger side
Tanks: 3.25" upper, 2" lower thick
Tubes: 0.63" thick

Bracket Mounted

13 lb. Radiator Cap included
Transmission Cooler included (1/2 20 Straight Thread, Inverted Flare)

When using electric fans:
One 16" or two 12" Electric fan(s) recommended for this core size (sold separately)
