CC42OL-42OLFS12CSP 3 Row Combo

Champion All Aluminum Radiator PLUS
Aluminum Shroud and (2) SPAL-1522 12" Fans
3-Row Core | Cools up to 500hp

Radiator Dimensions:
Total: 29.87" tall (with cap) x 22.63" wide (with brackets)
Core: 24" tall x 20.13" wide x 2" thick
Inlet: 1.5" center
Outlet: 1.75" passenger side
Tanks: top 3.5" thick, bottom 1.5" Thick
Tubes: 0.63" thick

Bracket Mounted

13lb. Radiator Cap included
Transmission Cooler NOT included
