CC4146 3 Row

Champion All Aluminum Radiator
Straight 6 cylinder engines only
3-Row Core | Cools up to 500hp

Radiator Dimensions:
Total: 28.25" tall (with cap) x 20.75" wide (with brackets)
Core: 22.38" tall x 18" wide x 2" thick
Inlet: 1.13" center
Outlet: 1.38" passenger side
Tanks: 2.38" thick
Tubes: 0.63" thick

Bracket Mounted
Brackets are on engine side of core

13lb. Radiator Cap included
Transmission Cooler NOT included

When using electric fans:
One 16" Electric fan recommended for this core size (sold separately)
