CC393 3 Row for L6's

Champion All Aluminum Radiator
3-Row Core | Cools up to 550hp
Note: This is the 18" tall core confirm core size before ordering

Radiator Dimensions:
Total: 23" tall (24.13" with cap) x 30.25" wide (with brackets)
Core: 18" tall x 23.5" wide x 2.5" thick
Inlet: 1.5" drivers side
Outlet: 1.75" passenger side
Tanks: 2.5" thick
Tubes: 0.63" thick

Bracket Mounted

13lb. Radiator Cap included
Transmission Cooler included (1/8-27NPT)

When using electric fans:
Two 11" SPAL Electric fans recommended for this core size (sold separetely)
