CC379-CY 3 Row Coyote Swaps

Champion All Aluminum Radiator
3-Row Core | Cools up to 600hp
For Coyote Swaps

Radiator Dimensions:
Total: 20.88" tall (21.5" with cap) x 25.75" wide (with brackets)
Core: 16.5" tall x 24.25" wide x 2" thick
Inlet: 1.5" passenger
Outlet: 1.5" driver
Tanks: 2.5" thick
Tubes: 0.63" thick

Saddle or Bracket Mounted

13lb. Radiator Cap included
Transmission Cooler included (1/8-27NPT)
Aluminum Shroud is also available (sold separately)

When using electric fans (sold separately):
One 16" or two 12" Electric fans recommended for this core size
