CC1492 3 Row Diesel

Champion All Aluminum Radiator
3-Row Core | Cools up to 800hp

Radiator Dimensions:
Total: 21.25" tall x 40.25" wide
Core: 18.87 tall x 34 wide x 2.25" thick
Inlet: 1.75 driver side
Outlet: 1.63 passenger side
Tanks: 2.88" thick
Tubes: 0.63" thick

Saddle Mounted

Transmission Cooler included: (5/8"/18 NPT)
Engine oil cooler: Metric 20-1.5

When using electric fans (sold separately):
Two 14" Electric fans or two 16" electric fans recommended for this core size
