AE718 2 Row 1" Tubes

Champion All Aluminum Radiator
2-Row Core: 1" Tubes | Cools up to 700hp

Radiator Dimensions:
Total: 19" tall x 32.5" wide
Core: 17" tall x 26.25" wide x 2.25" thick
Inlet: 1.3" Driver side
Outlet: 1.53" Passenger side
Tanks: 2.75" thick
Tubes: 1" thick

Radiator Cap Included
Transmission Cooler Included (1/2"- 20 STRAIGHT THREAD)

Saddle Mounted

When using electric fans:
One 16" or two 12" Spal fans recommended for this core size (sold separately)
